REDUCED SECTIONS, HIGHER PERFORMANCE

Aluminium system for casement opening, designed to meet the excellent value for money, quality/price, combining good thermal insulation, acoustic insulation, weather resistance, and a competitive positioning in the current market, being ideal not only for private buildings but also for constructions needing very high degrees of airtightness.

The innovative design, the use of high-quality components and the maximum 32-mm infill allow the windows to combine extraordinary properties of thermal insulation with the high strength of the aluminium structure.

ADVANTAGES:

• Open IN & Open out
• Contemporary & Stylish
• Minimum maintenance
• Widerange of profiles, shapes and finishing’s for every type of solution.
• Concealed hinges

PERFORMANCE:

• 45mm Outer frame Depth
• Maximum Frame Height-3000 mm
• Maximum Frame Width-1200mm
• Maximum Sash Height up to 3000 mm
• Maximum Sash Width upto 1000 mm
• Maximum load capacity -120 kg per sash
• Internal Glazing options from 6 mm to 32 mm. Single, Double & Triple Glass

MINIMAL DESIGN, MAXIMUM PERFORMANCE

Aluminium system uses larger insulation bars enabling superior thermal performance with the increased glazed surface while maintaining the same minimal aesthetics.

As in the previous system,Aluminium high-performance windows have slender, essential lines for contemporary aesthetics that aim at maximum luminosity while minimizing the visible surface of the profile. The result is a larger glazed area, high thermal and acoustic insulation that ensures unparalleled living comfort. The style of this refined, minimal design does not compromise the functionality and combines a sophisticated quality of insulating materials with the perfect functioning of the hidden accessories integrated within the profile itself. These factors enable the creation of heavy sash panels with maximum security against burglary.

ADVANTAGES:

• Minimal design built by using the visible profile (70 mm) and concealed accessories.
• Largerglazed surface and reduced profile area enable lower thermal transmittance (UW).
• Best quality materials with superior performance.
• Maximum resistance and luminosity
• Very minimal maintenance is required
• A wide range of colours and finishes to meet every building's aesthetic needs.

PERFORMANCE:

• Frame heat transfer Uf=1.4/2.56 W/m2K;
• Sound insulation: 44 dB;
• Airtightness: Classe A4;
• Watertightness: Classe R7;
• Wind resistance: 1500 N/m2 (safety 2250 N/m2).
